Atlantis Land AP1-54 - Manual (Page 22)

ENGLISH
22
2. Select TCP/IP Protocol and click Properties.
3. Select the Obtain an IP address from a DHCP
server radio button and click OK.
4. Select the IP Address tab. In this page, click the
Specify an IP address radio button (EG
IP=192.168.1.2 and subnet Mask=255.255.255.0).
Configuring PC (Windows 2000)
1. Go to Start / Settings / Control Panel. In the Control
Panel, double-click on Network and Dial-up
Connections.
2. Double-click LAN Area Connection.
3. In the LAN Area Connection Status window, click
Properties.
4. Select Internet Protocol (TCP/IP) and click
Properties.
5. Select Use the Following IP Address (EG
IP=192.168.1.2 and subnet Mask=255.255.255.0).
6. Click OK to finish the configuration.
Configuring PC (WindowsXP)
1. Go to Start / Control Panel (in Classic View). In the
Control Panel, double-click on Network Connections.
7. Double-click Local Area Connection.
