ENGLISH
18
1.3 The Rear Ports
PORT MEANING
POWER Jack
Connect the supplied power
adapter to this jack.
LAN
Connect an UTP Ethernet cable to
one of the four LAN ports when
connecting to a PC or an
office/home network of 10Mbps or
100Mbps.
Reset
After the device has turned on,
press it to reset the device or
restore to factory default settings.
Use a pin-shape item to push to
reset this device to factory default
settings. It will be useful too when
the manager forgot the password
to login, but the setting will be back
to default setting.
Reverse SMA
There is one 2dBi Gain Antenna in
the rear panel for wireless
connection.
