EXTERNAL
EQ
UIPMENT
SETUP
28
DVD SETUP
EXTERNAL EQUIPMENT SETUP
Component Connection
Connect the video outputs (Y, P B , P R
) of the DVD to the
C CO OM MPPO ON NEEN NT T IIN N V VIID DEEO O 1 1 or 2 2 jacks on the Media
Box. Match the jack colors (Y = green, P B = blue, and P R =
red).
Connect the audio outputs of the DVD to the
C
CO OM MPPO ON NEEN NT T IIN N A AU UD DIIO O 1 1 or 2 2 jacks on the Media
Box.
1. How to connect
2. How to use
■ Turn on the DVD player, insert a DVD.
■ Select the C Co om mp po onneenntt1 1 or C Co om mp po onneenntt2 2 input source
using the IIN NPPU UT T button on the remote control.
■ Refer to the DVD player's manual for operating instructions.
2
1
2 1 3
/DVI IN
RGB IN (P
RS-232C
IN
1
2
COMPONENT IN
L Y P B P R R
VIDEO AUDIO
VIDEO L
Y L R P B P R
1 2
HDMI Connection
1
2
COMPONENT IN
L Y P B P R R VIDEO
RGB IN (PC)
VIDEO AUDIO
L(MO
2 1 3
/DVI IN
HDMI OUTPUT
1
Connect the HDMI output of the DVD to the
H
HD DM MII//D DV VII IIN N 1 1, 2 2, 3 3, or H HD DM MII IIN N 4 4 jack on the
Media Box or H HD DM MII IIN N 5 5 on the TV.
No separate audio connection is necessary.
HDMI supports both audio and video.
1. How to connect
2. How to use
■ Select the H HD DM MII1 1 , H HD DM MII2 2 , H HD DM MII3 3 , H HD DM MII4 4 , or H HD DM MII5 5
input source using the IIN NPPU UT T button on the remote control.
■ Refer to the DVD player's manual for operating instructions.
2
1
G G Check HDMI cable over version 1.3.
If the HDMI cables don’t support HDMI version 1.3, it can
cause flickers or no screen display. In this case use the lat-
est cables that support HDMI version 1.3.
NOTE !
