CABLE MANAGEMENT
(For 55LHX)
■
Image shown may differ from your TV.
PROTECTIVE BRACKET FOR
POWER CORD
PROTECTIVE BRACKET FOR
POWER CORD
Connect the cables as necessary.
To connect additional equipment, see the
EXTERNAL EQUIPMENT SETUP section.
1
Loose the screw as shown.
Then, secure the power cord with the
PROTECTIVE BRACKET and reinstall the
screw again.
It will help prevent the power cord from being
removed by accident.
2
Install the PLUG IN TYPE HOLDER and put
the cable inside it.
3
Connect the cables as necessary.
To connect additional equipment, see the
EXTERNAL EQUIPMENT SETUP section.
1
Loose the screw as shown.
Then, secure the power cord with the
PROTECTIVE BRACKET and reinstall the
screw again.
2
PLUG IN TYPE HOLDER
FOR DESK-TYPE STAND
FOR WALL MOUNT
