134 EXTERNAL CONTROL DEVICE SETUP
Communication Parameters
• Baud rate: 9600 bps (UART)
• Data length: 8 bits
• Parity : None
• Stop bit: 1 bit
• Communication code: ASCII code
• Use a crossed (reverse) cable.
Command reference list
COMMAND1 COMMAND2 DATA
(Hexadecimal) COMMAND1 COMMAND2 DATA
(Hexadecimal)
01. Power k a 00 – 01 14. Treble k r 00 - 64
02. Input Select x b (See p.136 .) 15. Bass k s 00 - 64
03. Aspect Ratio k c (See p.136 .) 16. Balance k t 00 - 64
04. Screen Mute k d 00 - 01 17. 3D (For 3D TV) x t (See p.137 .)
05. Volume Mute k e 00 - 01 18. Color
Temperature x u 00 - 64
06. Volume Control k f 00 - 64 19. Extended 3D
(For 3D TV) x v (See p.137 .)
07. Contrast k g 00 - 64 20. ISM Method (
P la s m a
)
j p (See p.137 .)
08. Brightness k h 00 - 64 21. Energy Saving j q (See p.137 .)
09. Color k i 00 - 64 22. Auto
Configuration j u (See p.137 .)
10. Tint k j 00 - 64 24. Channel Add/Del m b 00 – 01
11. Sharpness k k 00 - 64 25. Key m c (See p.138 .)
12. OSD Select k l 00 - 01 26. Backlight (
L C D
) m g 00 - 64
13. Remote Control
Lock Mode k m 00 - 01
COMMAND1 COMMAND2 DATA00
(Hexadecimal) DATA01
(Hexadecimal) DATA02
(Hexadecimal) DATA03
(Hexadecimal) DATA04
(Hexadecimal) DATA05
(Hexadecimal)
23. Channel
Tuning m a physical
program high major
program low major low minor high minor low attribute
ENGLISH
