- 10 -
Item Description
Status Displays the information about the status
of the communication (the BSSID of the
Access Point to which the card is
associated).
SSID The SSID is the unique name shared
among all points in your wireless
network. The name must be identical for
all devices and points attempting to
connect to the same network.
It shows the current SSID setting of the
Wireless Network Adapter.
Tx Rate Shows the current transfer rate. (1, 2, 5.5,
or 11Mbps or Auto)
Channel Shows the selected channel that is
currently used. (There are 14 channels
available, depends on the country.)
Link
Quality
Displays the link quality of the
connection between the Wireless
Network Adapter and the Access Point it
connects.
Signal
Strength Displays the signal strength of the
connection between the Wireless
Network Adapter and the Access Point it
connects.
Data Rate Displays the current transmitting and
receiving rate.
