Getting Started
11
Ge
tting S
tar
ted
1
Connecting the AC
Adapter
1. Connect the supplied AC power cord to the AC
adapter.
2. Connect the AC adapter cable to DC IN adapter
input.
3. Plug the AC power cord into an AC outlet. Then
the unit goes into standby mode.
Only use the AC adapter supplied with this
device. Do not use a power supply from
another device or manufacturer. Using any
other power cable or power supply may cause
damage to the device and void your warranty.
>
Caution
How to Attach the
Ferrite Core (For EMI
Only)
You must affix the core (supplied with the model
you purchased) in order to reduce or eliminate
electrical interference.
1. Pull the stopper [a] of the ferrite core to open.
2. Wind the portable cables once on the ferrite
core.
3. Close the ferrite core until it clicks.
ND3520-NM.BUSALLK_1755_ENG.indd 11
2012-09-05 2:34:44
