Names of parts
7
Names of parts
Main Body
Connecting Part
Front remote control sensor /
Light sensor for automatic color adjustment Foot adjusting button
Rear remote
control sensor
Control panel
* The projector is manufactured using high-precision technology. You may, however, see on the Projector
screen tiny black points and/or bright points (red, blue, or green). This can be a normal result of the
manufacturing process and does not always indicate a malfunction.
Focus ring
Zoom ring
RS-232C S-VIDEO VIDEO RGB IN
AC IN
RGB OUT
HDMI IN COMPONENT IN
P R P B Y
USB
(SVC ONLY)
RS-232C
S-VIDEO
USB(SVC ONLY)
COMPONENT IN
RGB IN
VIDEO
AC IN
Kensington Security
System Connector
(Refer to page 14)
HDMI IN
RGB OUT
