Connection
18
Connecting to a DVD
< How to connect >
a.Connect the DVD component cable to the P
R
, P
B
and Y of
the COMPONENT IN of the projector.
* When connecting the component cable, match the jack colors
with the component cable.(Y=green, P
B
=blue, P
R
=red)
b. HDMI mode can be set only when your DVD player has a
HDMI port.
RS-232C
S-VIDEO
VIDEO
RGB IN
AC IN
RGB OUT
HDMI IN
COMPONENT IN
P
R
P
B
Y
USB
(SVC ONLY)
P
R
P
B
Y
(R) AUDIO (L)
* The output jacks (Y, P
B
, P
R
) of the DVD might be labelled as Y, Pb, Pr / Y, B-Y, R-Y / Y, Cb, Cr according to the equipment.
Component cable
HDMI Cable
Connecting to a D-TV Set-Top Box
< How to connect an RGB source >
a. Connect the RCB IN of the projector and the output port of
the DTV set-top box with computer cable.
b. Use a DTV receiver with DTV 480p(576p)/720p/1080i mode.
< How to connect a HDMI source >
a. Connect the HDMI IN of the projector and the HDMI output
port of the DTV set-top box withHDMI cable.
b. Use a DTV receiver with DTV 480p(576p)/720p/1080i mode.
RS-232C
S-VIDEO
VIDEO
RGB IN
AC IN
RGB OUT
HDMI IN
COMPONENT IN
PR
PB
Y
USB
(SVC ONLY)
(R) AUDIO (L)
DTV OUTPUT
DVI OUTPUT
PR
PB
Y
HDMI OUTPUT
RS-232C
S-VIDEO
VIDEO
RGB IN
AC IN
RGB OUT
HDMI IN
COMPONENT IN
P
R
P
B
Y
USB
(SVC ONLY)
(R) AUDIO (L)
DTV OUTPUT
DVI OUTPUT
P
R
P
B
Y
HDMI OUTPUT
* To receive D-TV programmes, it is necessary to purchase a D-TV receiver (Set-Top Box) and connect it to the projector.
* Please refer to the owner's manual of the D-TV Set-Top Box for the connection between projector and D-TV Set-Top Box.
Component cable
< How to connect a Component source >
a. Connect the component cable connected to the DTV set-top
box to the P
R
, P
B
and Y of the COMPONENT IN of the pro-
jector.
* When connecting the component cable, match the jack colors
with the component cable.(Y=green, P
B
=blue, P
R
=red)
RS-232C
S-VIDEO
VIDEO
RGB IN
AC IN
RGB OUT
HDMI IN
COMPONENT IN
P
R
P
B
Y
USB
(SVC ONLY)
(R) AUDIO (L)
DTV OUTPUT
DVI OUTPUT
P
R
P
B
Y
Signal
480i
480p
720p
1080i
576i
576p
Component
O
O
O
O
O
O
RGB/DTV
X
O
O
O
X
O
HDMI/DVI
X
O
O
O
X
O
Computer Cable
