Composite (RCA) Connection

Connect the A

A U

U D

D II O

O/V

V II D

D E

E O

O jacks between TV and

VCR. Match the jack colors (Video = yellow, Audio Left
= white, and Audio Right = red)

1. How to connect

2. How to use

■

Insert a video tape into the VCR and press PLAY on the
VCR. (Refer to the VCR owner’s manual.)

■

Select the A

A V

V 1

1 input source on the TV using the II N

N P

P U

U T

button on the remote control.

■

If connected to A

V IIN

N 2

2, select A

2 input source on the

TV.

If you have a mono VCR, connect the audio cable
from the VCR to the A

DIIO

O LL//M

O jack of the

TV.
