Composite connection – LG 55EA8800 User Manual
Page 22
ENGLISH
22
MAKING CONNECTIONS
Composite connection
Transmits analog video and audio signals from an external device to the TV. Connect the external device and the TV with the composite
cable as shown in the following illustration.
y
y
If you have a mono VCR, connect the audio cable from the VCR to the AUDIO L/MONO jack of the TV.
y
y
Check to ensure the cables are matched with the corresponding color connection.
NOTE
VIDEO
L
(MONO)
AUDIO
R
(*Not Provided)
YELL
O
W
WHITE
RED
WHITE
YELL
O
W
RED
WHITE
YELL
O
W
RED
VCR / DVD / Blu-Ray / HD Cable Box
YELLOW
(Use the composite video cable provided.)
