APPENDIX
111
Transmission / Receiving Protocol
T Trraan nssm miissssiio on n
[Command 1] : First command to control the set. (j, k, m or x)
[Command 2] : Second command to control the set.
[Set ID] : You can adjust the set ID to choose desired TV ID
number in Setup menu. Adjustment range is 1 ~ 99.
When selecting Set ID ‘0’, every connected the TV
is controlled. Set ID is indicated as decimal (1 ~
99) on menu and as Hexa decimal (0x0 ~ 0x63)
on transmission/receiving protocol.
[DATA] : To transmit command data.
Transmit ‘FF’ data to read status of command.
[Cr] : Carriage Return
ASCII code ‘0x0D’
[ ] : ASCII code ‘space (0x20)’
O OK K A Acckkn no ow wlle ed dg ge em me en ntt
The TV transmits ACK (acknowledgement) based on this for-
mat when receiving normal data. At this time, if the data is
data read mode, it indicates present status data. If the data is
data write mode, it returns the data of the PC computer.
E Errrro orr A Acckkn no ow wlle ed dg ge em me en ntt
The TV transmits ACK (acknowledgement) based on this for-
mat when receiving abnormal data from non-viable functions
or communication errors.
Data1: Illegal Code
Data2: Not supported function
Data3: Wait more time
[[C Co om mm maannd d1 1]][[C Co om mm maannd d2 2]][[ ]][[SSeett IID D]][[ ]][[D Daattaa]][[C Crr]] [[C Co om mm maannd d2 2]][[ ]][[SSeett IID D]][[ ]][[O OK K]][[D Daattaa]][[xx]]
[[C Co om mm maannd d2 2]][[ ]][[SSeett IID D]][[ ]][[N NG G]][[D Daattaa]][[xx]]
C CO OM MM MA AN ND D1 1 C CO OM MM MA AN ND D2 2
DATA
(Hexadecimal)
C CO OM MM MA AN ND D1 1 C CO OM MM MA AN ND D2 2
DATA
(Hexadecimal)
01. Power k a 0 ~ 1
02. Input Select k b 0 ~ 8
03. Aspect Ratio k c See p.112
04. Screen Mute k d 0 ~ 1
05. Volume Mute k e 0 ~ 1
06. Volume Control k f 0 ~ 64
07. Contrast k g 0 ~ 64
08. Brightness k h 0 ~ 64
09. Colour k i 0 ~ 64
10. Tint k j 0 ~ 64
11. Sharpness k k 0 ~ 64
12. Back Light m g See p.113
13. OSD Select k l 0 ~ 1
14. Remote Control/Key Lock k m 0 ~ 1
15. Treble k r 0 ~ 64
Command Reference List
16. Bass k s 0 ~ 64
17. Balance k t 0 ~ 64
18. Colour Temperature k u 0 ~ 3
19. Red Adjustment k v0 ~ C8
20. Green Adjustment k w 0 ~ C8
21. Blue Adjustment k $ 0 ~ C8
22. Channel Tuning m a See p.114
23. ISM Method j p 0 ~ 3
24. Low Power j q 0 ~ 1
25. Orbiter Time
j r 1~ FE
Setting
26. Orbiter Pixel
j s 1~ 3
Setting
27. Send IR Code m c See p.114
28. Input Select x b See p.114
Plasma TV models only
