PREPARATION
14
1
Connect the cables as necessary.
To connect additional equipment, see the
EXTERNAL EQUIPMENT SETUP section.
2 Open the CABLE MANAGEMENT CLIP as
shown.
42/47LE5350, 32/42/47/55LE5400,
42/47/55LE5500, 42/47/55LE7500,
47/55LE8500, 42/47/55LX6500
1
Secure the power cord with the CABLE
HOLDER on the TV back cover.
It will help prevent the power cable from
being removed by accident.
2
After connecting the cables as necessary,
install the CABLE HOLDER as shown and
bundle the cables.
32/42/46/52/60LD550, 47/55LD650
CABLE MANAGEMENT
ꔛ Image shown may differ from your TV.
3 Put the cables inside the CABLE
MANAGEMENT CLIP and snap it closed.
AC IN
AC IN
AC IN
CABLE MANAGEMENT CLIP
CABLE HOLDER
CABLE HOLDER
Plasma TV
CABLE HOLDER
1
After connecting the cables as necessary,
install the CABLE HOLDER as shown and
bundle the cables.
In case of the LAN cable, install as shown
to reduce the electromagnetic wave.
