2.16

Front Panel LAN Indicator Connector

(LAN_LED1)

Table 2.2: Front Panel LAN Indicator Connector

LAN Mode

Indicator

G-LAN Link ON

Green ON

G-LAN Active

Green Flash

G-LAN Link Off

Green OFF
