103
AIMB-766 User Manual
Appendix B
I/O Pin
A
ssignments
B.25
SPI_CN1: SPI fresh card pin connector
B.26
TPM_SLOT1: TPM module connector
Table B.25: SPI_CN1:SPI fresh card pin connector
Pin
Signal
Pin
Signal
1
+F1_3V
2
GND
3
F1_SPI_CS#_Q
4
F1_SPI_CLK_Q
5
F1_SPI_MISO_Q
6
F1_SPI_MOSI_Q
7
NC
8
NC
Table B.26: TPM_SLOT1:TPM module connector
Pin
Signal
Pin
Signal
1
GND
2
CLK
3
SMB_ CLK
4
FRAME#
5
SMB_DATA
6
REST
7
LAD2
8
LAD3
9
LAD1 10
VCC3
11
GND 12
LAD0
13
N/C
14
VCC3
15
SERIRQ# 16
VCC3SB
17
CLKRUN#
18
GND
19
N/C 20
SLPS3#
