STEP 6: ATTACH THE OVEN TO THE WALL
6. Roof vented installation:See Figure 33
Install ductwork through the vent opening in the upper
cabinet. Complete the venting system through the roof
according to the method needed. See “PREPARE THE
VENTING SYSTEM,” STEP 2 on the page 8. Use caulking
to seal exterior roof opening around the exhaust cap. See
Figure 6 on page 8.
7. Use power supply cord clamp to bundle the power supply
cord. Install the power supply cord clamp, using a screw as
shown in Figure 34, to inside of the cabinet.
8. To install the grease filter: Slide it into the slide slot, then
push up and toward oven center to lock.
See Figure 35.
9. Plug in the power supply cord.
10. Read your Owner’s Manual, then check the operation of
your microwave oven.
INSTALLATION
21
Figure 33
Figure 35
Figure 34
damper
duct
power
supply
cord
clamp
