Asante Technologies FriendlyNet User Manual
Page 12
LED Indicators
Page 3-2
Link/Activity LEDs
The green Link/Activity LEDs, associated with each 10Base-T port,
illuminate if a twisted-pair link is connected.
Table 3-1 Link/Activity LEDs
On
•
Normal data/link pulse reception
Off
•
No twisted-pair cable connected
•
Link pulse disabled at other end
•
No power to the hub
•
Twisted-pair connection faulty
•
Non-10Base-T device at other end
•
Twisted-pair cable exceeds recom-
mended length
Blinking
•
Receiving network traffic
