42 Language Dictionary

STAT:OPER:ENAB

This command and its query set and read the value of the Operational Enable register. This register is a mask for enabling
specific bits from the Operation Event register to set the operation summary bit (OPER) of the Status Byte register. This bit
(bit 7) is the logical OR of all the Operational Event register bits that are enabled by the Status Operation Enable register.

Command Syntax

STATus:OPERation:ENABle

Parameters

0 to 32727

Suffix

(None)

Default Value

Examples

STAT:OPER:ENAB 1312 STAT:OPER:ENAB 1
STATUS:OPERATION:ENABLE?

Query Syntax

STATus:OPERation:ENABle?

Returned Parameters

(Register value)

Related Commands

STAT:OPER:EVEN

STAT:OPER NTR
STAT:OPER PTR

These commands set or read the value of the Operation NTR (Negative-Transition) and PTR (Positive-Transition) registers.
These registers serve as polarity filters between the Operation Enable and Operation Event registers to cause the following
actions:

•

When a bit in the Operation NTR register is set to 1, then a 1-to-0 transition of the corresponding bit in the

Operation Condition register causes that bit in the Operation Event register to be set.

•

When a bit of the Operation PTR register is set to 1, then a 0-to-1 transition of the corresponding bit in the

Operation Condition register causes that bit in the Operation Event register to be set.

•

If the same bits in both NTR and PTR registers are set to 1, then any transition of that bit at the Operation

Condition register sets the corresponding bit in the Operation Event register.

•

If the same bits in both NTR and PTR registers are set to 0, then no transition of that bit at the Operation

Condition register can set the corresponding bit in the Operation Event register.

Note

Setting a bit in the value of the PTR or NTR filter can of itself generate positive or negative
events in the corresponding Operation Event register.

Command Syntax

STATus:OPERtion:NTRansition

STATus:OPERtion:PTRansition
