22 Remote Programming
Programming Some Power Supply Functions (continued)
1220
CALL IOENTER (PS,OEVENT)
'Read back event bit
1225
IF PCIB.ERR < > NOERR THEN ERROR PCIB.BASERR
1230
IF (OEVENT AND 1024) = 1024 THEN PRINT "Supply switched to CC mode."
1240
'Clear the status circuit
1245
CODES$ = "*CLS" :GOSUB 2000
1260
FOR I = 1 TO 100 :NEXT I
'Wait for supply to clear
1265
‘
1260
'Disable output and save present state in location 2
1265
CODES$ = "OUTPUT OFF;*SAV 2"
:GOSUB 2000
1270
END
1275
‘
2000
'Send command to power supply
2005
LENGTH = LEN(CODES$)
2010
CALL IOOUTPUTS (PS,CODES$,LENGTH)
'Send command to interface
2015
IF PCIB.ERR < > NOERR THEN ERROR PCIB.BASERR
ISETUP.BAS error trap
2020
RETURN
2025
‘
3000
'Get data from power supply
3005
CALL IOENTERA (PS,OUTPUTS(1),MAX.ELEMENTS,ACTUAL.ELEMENTS)
3010
IF PCIB.ERR < > NOERR THEN ERROR PCIB.BASERR
3015
RETURN
******************************************************************************************************
IBM Controller Using National Interface
******************************************************************************************************
990
‘ --------------------- Merge DECL.BAS here ------------------------
1000
'Power Supply Variable = PS% ; Stand-Alone Address = 706
1005
CODES$=SPACE$(50):MODE$=SPACE$(5):OEVENT$=SPACE$(20)
1010
D$=SPACE$(60):OUTPUT$=SPACE$(40):BDNAME$=“PS%"
1015
DIM OUTPUT(2)
1020
‘
1025
'Set up power supply interface for DOS driver
1030
CALL IBFIND(BDNAME$,PS%)
1035
IF PS% 1040 CALL IBCLR(PS%) 1045 ‘ 1050 'Program power supply to CV mode with following voltage and current 1055 CODES$ = "VOLTAGE 7.8;CURRENT 480” :GOSUB 2000 1060 ‘ 1065 'Query power supply outputs and print to screen 1070 CODES$ = "MEASURE:VOLTAGE?;CURRENT?" :GOSUB 2000 :GOSUB 3000 1075 VOUT = OUTPUT(1) 1080 IOUT = OUTPUT(2) 1085 PRINT "The programmed levels are "VOUT" Volts and "IOUT" Amps" 1090 ‘ 1095 'Program triggered current level to value insufficient to maintain 1100 'supply within its CV operating characteristic 1105 CODES$ = "CURR:TRIG 50" :GOSUB 200 1110 ‘ 1115 'Set operation status mask to detect mode change from CV to CC 1120 CODES$ = "STAT:OPER:ENAB 1024;PTR 1024" :GOSUB 2000 1125 ‘
