Language Dictionary 39

Output Subsystem

This subsystem controls the power supply's voltage and current outputs and an optional output relay.

Do not install or program the Agilent Relay Accessories if the power supply maximum output current
rating (see Table 3-1) exceeds the contact ratings of the relay.

OUTP

This command enables or disables the power supply output. The state of a disabled output is a condition of zero output
voltage and a model-dependent minimum source current (see Table 3-1). The query form returns the output state.

Commandd Syntax

OUTPut[:STATe]

Parameters

0 | OFF | 1 | ON

Suffix

(None)

*RST Value

Examples

OUTP 1 OUTPUT:STATE ON

Query Syntax

OUTPut(:STATe]?

Returned Parameters

0 or 1

Related Commands

*RST *RCL *SAV

OUTP:PROT:CLE
OUTP:PROT:DEL

OUTP:PROT:CLE

Clears any OV (overvoltage), OC (overcurrent, unless set via external voltage control),OT
(overtemperature), or RI (remote inhibit) protection features. After this command, the output is
restored to the state it was in before the protection feature occurred.

OUTP:PROT:DEL

Sets the time between the programming of an output change that produces a CV, CC, or
UNREG condition and the recording of that condition by the Status Operation Condition
register. The delay prevents the momentary changes in power supply status that can occur
during reprogramming from being registered as events by the status subsystem. Since the delay
applies to CC status, it also delays the OCP (overcurrent protection) feature. The OVP
(overvoltage protection) feature is not affected by this delay.

Examples

OUTP:PROT:CLE OUTPUT:PROTECTION:CLEAR

OUTPUT:PROTECTION:DELAY 75E-1

OUTP:PROT:DEL MIN OUTPUT:PROT:DELAY MAX

Query Syntax

OUTP:PROT:CLE (None)

OUTPut:PROTection:DELay? OUTPut:PROTection:DELay? MIN
OUTPut:PROTection:DELay? MAX
