LUMATEQ LK848-20-110-00 User Manual

Instructions, Caution, Preparation

LUMATEQ is a division of TACO Metals, Inc.

To view the entire portfolio of LUMATEQ products and for Warranty and Product Information, go to lumateq.com

INSTRUCTIONS

Connecting Terminals

Front Lens

LED Tubes

Lampholder

Tube Fixing Board

Fixing Pole

Wire Gland Cap

Wire Gland

Wire Gland Bottom

Back Cover

Front Wall Fixing Clip

Back Wall Fixing Clip

Lens and Back Fixing Clip

Screw

Wire

Preparation

• Before beginning assembly, installation, or operation of product, make sure all parts are present. Compare parts with the

package contents list and diagram.

• If any part is missing or damaged, do not attempt to assemble, install or operate the product. Contact customer service at

305.770.2392 or visit our website at www.LUMATEQ.com for replacement parts.

Dimension /

Content

Caution

•

Risk of fire/electrical shock. If not qualified, consult an electrician.

•

Disconnect power at fuse or circuit breaker before installing or servicing.

•

Edges may cut. Handle with care.

•

UL Listed for indoor use only.

•

Connect fixture to 110-277 volt, 60 Hz power source. (Any other connection may void warranty.)

•

A qualified electrician or person with experience in household wiring should install this fixture. The electrical system and the

method of connecting to electricity must be in accordance with the National Electrical Code and local building codes.

•

Keep away from flammable objects. Do not position fixture within one inch of any combustible materials.

•

Your light fixture is pre-wired for easy installation.

•

This fixture is rated for 50,000 hrs. When inside LED tubes need to be replaced, please contact LUMATEQ to get new tubes.

Use of any other tubes will void the warranty.

•

To avoid hazard to children, account for all parts and destroy packing materials.

WARNING

Vapor Proof Kit (LK848-20-110-00)

49.5"

33.0"

4.0"

6.0"

*non-submersible
