SuperSmart User’s Guide
Hardware Description 2-7
The system tests each component one at a time. The unit will
complete the test cycle even if a problem is detected on any of
the components. If no lights are ON, this means that all the hub
components passed the diagnostics. If any problems were
detected, the corresponding LED will blink after test
completion to indicate which component failed the test.
Configure Button
On the left front panel is a button labeled Configure . Use this
button for the following configuration functions:
•
Segment Setting
•
Demo (LED display demonstration)
•
Diagnostics
•
Reset
Move from one function to the next by using a "long press" on
the button. LED indicators will light up depending on the
selected system function. Make necessary choices within the
current function using a "short press". Then, use a "long press"
to effect your choice and move on to the next function. See
Using the Configure Button in Chapter 4 for related information.
F
"Long press" in this User’s Guide means pressing the Configure button for
more than 2 seconds and then releasing it. "Short press" means pressing
the Configure button and immediately releasing it. Also, if the button is not
pressed within 10 seconds, the system returns to normal operation.
