12
Setting Surface Controls
Available power level settings
Your surface control provides varied settings for
each heating zone (except the warmer zone).
These power levels include ON (--), Lo (10%), 5.0
(medium 50%), and Hi (100%). See Figure 1
though Figure 4.
The + and - keys provide incremental adjustments
for precise control when changing surface settings.
Low heat settings (between 0.0 and 2.8) change
with more precision. High heat settings (between
3.0 to HI) will change faster. See Figure 5.
Element size indicators
Some cooktop zone positions offer two different
element sizes. At these locations, you may choose
to use the inner element only or you may expand
the heating area with a press of the BURNER SIZE
key.
The number of circles displayed at the element
zone LED represents the number of heating rings
available for that position.
• 1 circle = single element
• 2 circles = double element
Cooktop power level settings
Fig. 5
Setting / Power Incremental change
Lo to 3.0 (10-30%) 0.2
3.0 to HI (30-100%) 0.5
Display Settings Changes
Fig.1 Fig. 2
Fig. 3 Fig. 4
