AS PRG-1000
AUTOSTART TECH TOOL
PRG-1000 Parts
The PRG-1000 includes:
• The handheld unit and a 9-volt battery;
• The PC-LINK adaptor, which enables communication between the PRG-1000 and
a personal computer. This connectivity with a personal computer offers the
capability of upgrading the PRG-1000 firmware and other additional features,
such as saving/recalling personal programming options files on a computer.
• The MODULE cable enables communication between the remote starter and the
PRG-1000. This T harness, which connects to the remote starter antenna, allows
the unit to be programmed and/or read even when the remote starter is powered
off.
Fig. 1
To PC-LINK
adapter
To computer USB
port
To PRG-1000
PC-LINK
connector
Fig. 2
Female to
Antenna
Male to Antenna
cable
To
PRG-1000
