*1: Auto transition = Mode changes by a command are not performed. It becomes a
“Coordinate Data
Mode (150pps)
” immediately after reset.
*2: Always open. If connected with V
CC
, V
SS
, or other circuit, an error operation may occur.
*3: About pin number 14, 15 and 16, immediately after a power supply injection, it works as an input
terminal and becomes an output terminal after that. Do not open these terminals.
*4: If neither SW0 nor SW1 function is used, connect 28 and 29 pins to GND directly.
