Document No. DER-S0100A 18 Version 1.4 ©2012 DMC Co., Ltd.
TSC-40/IC Product Specification
11. Changes and improvements
11-1. Version history
§ TSC-40/IC
Ver0.1 (October 3, 2007)
Draft release
Ver0.2 (December 10, 2007)
5-3. Timing requirement External clock timing Clerk mistake was corrected.
Input cycle 500ns → 166ns
Clock pulse 200ns → 70ns
6-6. Product name label specification “Pb Free” was added.
Ver0.3 (January 21, 2008)
Circuit Diagram 5-Wire Resistive Touch Screen
Corrected the 15
th
-Pin (SEL3/EEP_CLK) to connection with Vcc via resistance.
Ver1.0 (March 13, 2008)
First release
(Change from ver0.3)
1-4. General specification Input response time was added.
3. Pin functions Detail information was added in 22, 23, 24 pin.
9. Terminal Pin Specification was added.
Document number was added.
Circuit Diagram Part number was added. (Rev 2)
Ver1.1 (June 30, 2008)
5-2. Recommended operational conditions (TTL input level selected) was deleted.
Ver1.2 (July 2, 2008)
1-4. General specification Power supply voltage DC 2.4V to 5.5V → DC 3.3V to 5.5V
Ver1.3 (March 30, 2011)
5-3. External clock timing “Input cycle ” (Minimum) 166ns → 165ns
6-1. Outline (Small group packaging) “damp-proof aluminum laminate bags or” was added.
6-3. Basic packaging “Packing sample” was added.
6-4. Small group packaging “Packing sample” was added.
6-4. Small group packaging “This is an example and may not be the same as supplies.” was added.
Ver1.4 (May 25, 2012)
Address has changed as Tokyo office had moved
