Installation and Connection Instructions
37
Connections
The water inlet and drain hoses, as well as the mains cable must be
connected beside the dishwasher because there is no space for them
behind the appliance.
The example plumbing and electrical installation given below can only
be regarded as a recommendation; the actual situation where the dish-
washer is to be installed will define the exact installation (available
connections, local electricity and water board regulations for connect-
ing up appliances, etc.).
Two 45° or Straight Connections,
Outer ø 19 mm, Length 30 mm
Double tap Water drain Water inlet
Water
drain Water
inlet Mains
cable Mains
cable Mains socket
