WD Series
Attractive surface mounting loudspeaker packages
with 10 oz. magnet and choice of transformer are
mounted in a sloped baffle with black fabric grille.
Models with (V) suffix include volume control option
WD417-72 System
SPECIFICATIONS
Model VP14 WD417-25 WD417-72 WD417-72V
SPEAKER TYPE 8" Dual Cone 8" Dual Cone 8" Dual Cone 8" Dual Cone
MAGNET WEIGHT 10 oz (226g) 10 oz (226g) 10 oz (226g) 10 oz (226g)
FREQUENCY RESPONSE 50Hz to 15kHz 50Hz to 15kHz 50Hz to 15kHz 50Hz to 15kHz
SENSITIVITY (1W/1M) 96dB 96dB 96dB 96dB
WATTS-PROGRAM 15 15 15 15
TRANSFORMER 25V/70.7V 25V/70.7V 25V/70.7V 25V/70.7V
TRANSFORMER TAPS 1/2W,1W,2W, 4W 1/2W,1W,2W, 4W 1/2W,1W,2W, 4W 1/2W,1W,2W, 4W
50 OHM POT No No No Yes
BAFFLE MATERIAL 14 Gauge CRS NA NA NA
ENCLOSURE MATERIAL 16 Gauge CRS MDF MDF MDF
FINISH "Wiremold" Beige Simulated Oak Simulated Oak Simulated Oak
DIMENSIONS:
LENGTH (Rear of Enclosure)
11.4" (290mm) 10.47" (266mm) 10.47" (266mm) 10.47" (266mm)
WIDTH 11.75" (298mm) 9.48" (241mm) 9.48" (241mm) 9.48" (241mm)
HEIGHT (Bottom of Enclosure) 2.876" (73mm) 3.75" (95mm) 3.75" (95mm) 3.75" (95mm)
HEIGHT (Top of Enclosure) 5.29" (134mm) 5.43" (138 mm) 5.43" (138 mm) 5.43" (138 mm)
