Rear View
1. Power Jack
The unit is designed to be non-powered (external power is not required - its
operating power comes from the computers). In general, the only time that
external power is necessary is when you cascade it, or if operation
becomes erratic because the unit isn’t obtaining enough power from the
computer connections. If you choose to use external power, the power
adapter cable plugs in here.
2. Console Port Section
w If this is a first station unit, your monitor, keyboard and mouse plug in
here.
w If this is a daisy chained unit, the cables that link back to a port on a
higher Master View unit plug in here.
3. CPU Port Section
The cables that link to the computers plug in here.
