Aiwa CDC-Z107 User Manual
Page 21
PIN NO.
BU (V)
BU+ACC (V)
FM (V)
AM(V)
CD (V)
AUX (V)
1
0
0
3.94
3.93
3.96
3.96
2
0
0
3.98
3.98
4.00
4.01
3
0
0
4.00
4.00
4.02
4.01
4 ~ 6
0
0
4.00
4.00
4.02
4.02
7
0
0
3.99
3.99
4.01
3.99
8 ~ 9
0
0
0
0
0
0
10
0
0
3.98
3.98
4.00
3.99
11
0
0
4.01
4.01
4.03
4.01
12
0
0
3.99
3.99
4.01
3.99
13
0
0
4.02
4.01
4.04
4.01
14
0
0
4.01
4.01
4.03
4.01
15 ~ 18
0
0
0
0
0
0
19
0
0
4.01
4.01
4.03
4.01
20 ~ 21
0
0
4.02
4.01
4.04
4.01
22
0
0
4.01
4.01
4.03
3.98
23
0
0
4.01
4.01
4.03
4.01
24
0
0
3.98
3.98
4.00
3.98
25 ~ 26
0
0
0
0
0
0
27
0
0
4.02
3.99
4.04
3.99
28
0
0
4.02
4.01
4.04
4.01
29
0
0
4.02
4.01
4.04
4.01
30 ~ 31
0
0
4.01
4.01
4.03
4.00
32
0
0
4.00
3.99
4.02
3.98
33
0
0
3.91
3.91
3.93
3.93
34
0
0
4.02
4.01
4.04
4.02
35
0
0
4.00
3.99
4.02
4.00
36
0
0
0
0
0
0
37 ~ 38
0
0
4.00
3.99
4.02
4.00
39
0
0
7.64
7.63
7.68
7.64
40
0
0
4.00
3.99
4.02
4.00
41
0
0
3.99
3.99
4.01
3.99
42
0
0
0
0
0
0
43
0
0
4.00
3.99
4.02
3.99
44
0
0
4.03
4.02
4.05
4.01
IC, LC75374E
- 21 -
