Specifications
Model HDMI-C5-S HDMI-C5-SR HDMI-C5-4 HDMI-C5-8
Description
1 Port HDMI
Transmitter
1 Port HDMI
Transceiver
4 Port HDMI
Transceiver
8 Port HDMI
Transceiver
Input HDMI Female x 1 RJ45 x 1 HDMI Female x 1 HDMI Female x 1
Output
HDMI Female x 1
RJ45 x 1
HDMI Female x 1
RJ45 LINK Out x 1
HDMI Female x 1
RJ45 HDMI Out x 4
RJ45 Link Out x 1
HDMI Female x 1
RJ45 HDMI Out x 8
RJ45 Link Out x 1
Max Distance
and Resolution
With each cascading length:
< 80m (275ft) @ 480p
< 70m (230ft) @ 720p / 1080i
< 30m (100ft) @ 1080p
Video Control EQ x 1
Signal Type HDMI
Power
Consumption
DC 5V 750mA DC 5V 750mA DC 5V 1.8A DC 5V 2.5A
Dimensions
(LxWxH)
Compact Size 62 x 113 x 29 1U, 240 x 180 x 44
