TREK-305R User Manual 4
1.3 Quick Installation Guide
1. Connect 26pin connector to 5.7” panel.
Figure 1.2 - 2 m cable connecting VITA and TREK
2. Connect 36pin connector to VITA-350P.
Figure 1.3 Backside of TREK-305R
DI/O (default: 4 Digital output)
26 pin (S1)
connect to
TREK-305R
36pin (S2)
connect to
VITA series
Speaker
2 types of VESA mount:
30 x 38mm and 75 x 75mm
Warranty void if sticker is removed.
Please refer to Advantech RMA policy
http://erma.advantech.com.tw/GlobalPolicy.asp
Warranty vo
id
if removed
