3 TREK-305R User Manual
Chapter 1
G
eneral
Information
1.2 Features
Display
Type QVGA TFT LCD (Toshiba LT057A344F)
Colors 18 bits (256 k)
Resolution 320 x 240
Size (disgonal) 5.7” (4:3)
Pixel Pitch 0.36 (W) x 0.36 (W)
View Angle (H°, V°) H: 140°, V: 120°
Brightness 320 nits by LED backlight
Touchscreen 4-wire resistive
Contrast Ratio 500
Backlight Life Time (hrs) 20000
I/O
LVDS 1 x 26 pin connector
Audio 2 Watt speaker out
Power
DC Input 3.3 V and 5 V
LCD power button Push button
Power Consumption 1.3 W
Mechanical
Mounting VESA mount (30 x 38 mm, 75 x 75 mm)
Material PC
Weight 400 (g)
Dimension W x H x D (mm) 168.55 x 128.05 x 35.6
Enviroment
Operating Temperature -10 ~ 70°C
Storage Temperature -30 ~ 80°C
Vibration MIL-STD-810F 514.5C-3
Certification
FCC FCC 47 CFR part 15B
IC ICES-003 issue 4
CE EN55022/55024
E13 ECE-R10 (v.03)
BSMI CNS 13438
