Ask Proxima M2+ User Manual
Page 10
3
F
IGURE
2
Front view of projector
F
IGURE
3
Rear view of projector
F
IGURE
4
Bottom view of projector
keypad
zoom ring
focus ring
remote control sensor (IR)
connectors
power connector
security lock
remote control sensor (IR)
adjustable foot
speaker
foot release
lamp housing
leveling foot
