COMBITOUCH™ ES SERIES • ELECTRIC INSTALLATION MANUAL • 31.
I N S T A L L A T I O N
E R R O R C O D E S
Error
Code
Display Shows
Model Mode
ES
ESG
ESI
Steam Combination Convection Retherm
E01 Low Water Boiler Yes No No No To 365°F No
E02 Control Temp High Yes Yes No No No No
E03 Fan Motor Error Yes Yes No No No No
E11 Convection Temperature High Yes Yes BOILER UNITS
ONLY
No No No
E13 Boiler Temperature High Yes No No No Yes No
E15 Condensor Temperature High Yes Yes No No To 356°F No
E20 B11 Core Temperature Probe Single
Point Fault - HACCP only Yes Yes No No No No
E21 N6 Cavity Probe Fault Yes Yes BOILER UNITS
ONLY
No No No
E22 B10 Core Temp Probe Fault Yes Yes BY TIME ONLY BY TIME ONLY BY TIME ONLY BY TIME ONLY
E23 B4 Boiler Probe Fault Yes No No No No No
E24 B5 Bypass Probe Fault Yes Yes No No Yes No
E25 B3 Condensor Probe Fault Yes Yes Yes No To 356°F No
E26 N8 Boiler Safety Temperature Probe Fault Yes No No No No No
E27 Boiler Element Temperature High Yes No No No Yes No
E34 Steam Generator Drain Pump Fault Yes No No No No No
E35 Vent Not Closed Yes Yes Yes
( NO BROWNING )
Yes
( NO BROWNING )
Yes
( NO BROWNING )
Yes
( NO BROWNING )
E36 Steam Temperature High Yes No No No Yes No
E40 B3 Condensor Probe Short to Frame Yes Yes No No To 356°F No
E41 B4 Boiler Probe Short to Frame Yes No No No Yes No
E42 B5 Bypass Probe Short to Frame Yes Yes No No Yes No
E43 N6 Cavity Probe Short to Frame Yes Yes BOILER UNITS
ONLY
No No No
E44 N8 Boiler Safety Temperature Probe Short
to Frame Yes No No No Yes No
E45 B10 Core Temperature Probe Short to Frame Yes Yes BY TIME ONLY BY TIME ONLY BY TIME ONLY BY TIME ONLY
E51 No Water in Boiler Yes No No No Yes No
E53 Fan Motor High Temperature Yes Yes No No No No
E55 Vent Not Open Yes Yes Yes
( NO BROWNING )
Yes
( NO BROWNING )
Yes
( NO BROWNING )
Yes
( NO BROWNING )
E57 No Rinse Water Yes Yes Yes Yes Yes Yes
E93 Communication Error FROM Display Board Yes Yes No No No No
E94 Communication Error, TO Display Board Yes Yes No No No No
E96 Communication Error, TO RBL Yes Yes No No No No
E97 Communication Error, FROM RBL Yes Yes No No No No
When the oven malfunctions, an error code will appear in the display.
PRESS THE START ICON TO ACKNOWLEDGE THE ERROR.
The icons that begin to flash represent operational modes that are still usable.
When the oven fault is corrected, the Combitherm will return to normal Operation.
