19 Alcatel-Lucent | OmniSwitch 9000
Ordering information
BUNDLES
OS9600-CB-A OS9600 base bundle, to include OS9600 chassis, fan tray, 1 CMM, 1 PSU
OS9600-RCB-A OS9600 redundant bundle, to include OS9600 chassis, fan tray, 1 CMM, 2 PSUs
OS9700-CB-A OS9700 base bundle, to include OS9700 chassis, fan tray, 1 CMM, 2 PSUs
OS9700-RCB-A OS9700 redundant bundle, to include OS9700 chassis, fan tray, 2 CMM, 3 PSUs
OS9800-CB-A OS9800 base bundle, to include OS9800 chassis, fan tray, 1 CMM, 3 PSUs
OS9800-RCB-A OS9800 redundant bundle, to include OS9800 chassis, fan tray, 2 CMMs, 4 PSUs
CHASSIS AND POWER SUPPLIES
OS9600-CHASSIS OS9600 chassis and fan tray
OS9700-CHASSIS OS9700 chassis and fan tray
OS9800-CHASSIS OS9800 chassis and fan tray
OS9-PSU-0600A 600W AC PSU (100-240V) for OS9000
OS9-PSU-0600D 600W DC PSU (48V) for OS9000
OS9-IP-SHELF External PoE rack for the OS9000 chassis. Rack to include 1 PSU (OS9-IPS-0600A)
OS9-IPS-0600A 600W AC power-over-Ethernet PSU (100-240V) for use with OS9-IPSHELF only
OS9-IPS-0390A 390W AC power-over-Ethernet PSU (100-240V) for standalone use 3
OS9-IPS-0230A 240W AC power-over-Ethernet PSU (100-240V) for standalone use 3
MANAGEMENT AND FABRIC MODULES
OS9600-CMM Chassis Management Module for the OS9600 and OS9700 4
OS9700-CMM Chassis Management Module for the OS9600 and OS9700 4
OS9800-CMM Chassis Management Module for the OS9800
SOFTWARE
OS9-C20L-UPG Software upgrade for OS9-GNI-C20L to provide 1000BaseT support on RJ45 ports (one license required per module)
NETWORK INTERFACE CARDS
OS9-XNI-U2 2-port 10GigE XFP
OS9-XNI-U6 6-port 10GigE XFP
OS9-GNI-U24 24-port GigE SFP
OS9-GNI-C24 24-port GigE (10/100/1000) RJ45
OS9-GNI-P24 24-port GigE (10/100/1000) RJ45 w/PoE
OS9-GNI-C48T 48-port GigE (10/100/1000) MRJ21
OS9-GNI-C20L 20-port Fast Ethernet (10/100 – SW upgradable to 10/100/1000) RJ45 and 2-port GigE (100/1000) SFP
TRANSCEIVERS AND CABLES
XFP-10G-SR 10 Gigabit Ethernet optical transceiver (XFP MSA – up to 2km)
XFP-10G-LR 10 Gigabit Ethernet optical transceiver (XFP MSA – up to 10km)
XFP-10G-ER40 10 Gigabit Ethernet optical transceiver (XFP MSA – up to 40km)
XFP-10G-ZR80 10 Gigabit Ethernet optical transceiver (XFP MSA – up to 80km)
SFP-GIG-SX Gigabit Ethernet optical transceiver (SFP MSA – up to 550m)
SFP-GIG-LX Gigabit Ethernet optical transceiver (SFP MSA – up to 10km)
SFP-GIG-LH40 Gigabit Ethernet optical transceiver (SFP MSA – up to 40km)
SFP-GIG-LH70 Gigabit Ethernet optical transceiver (SFP MSA – up to 70km)
SFP-GIG-xxCWD60 Gigabit Ethernet CWDM optical transceiver (SFP MSA – up to 60km – 8 wavelengths)
SFP-GIG-EXTND Gigabit Ethernet optical transceiver (SFP MSA – Gigabit extender up to 2km)
SFP-DUAL-MM Dual Speed (100FX – 1000LX) optical transceiver (SFP MSA – up to 2km (FX) / 550m (LX))
SFP-DUAL-SM10 Dual Speed (100FX – 1000LX) optical transceiver (SFP MSA – up to 10km (FX and LX))
MRJ21-COMBO-2 2m combo set for OS9-GNI-C48T composed of 8 cables (2m, MRJ21 to RJ45) and 1 patch panel
MRJ21-COMBO-5 5m combo set for OS9-GNI-C48T composed of 8 cables (5m, MRJ21 to RJ45) and 1 patch panel
MRJ21-COMBO-10 10m combo set for OS9-GNI-C48T composed of 8 cables (10m, MRJ21 to RJ45) and 1 patch panel
(3) Supported only on the OS9600
(4) The CMM for the OS9600 and OS9700 are identical
