DRS220 User’s Guide
10
Tank Capacity Mode Training
1. While holding down, press . The SET TANK indicator will turn on, and
OFF will show on the display. This indicates that the Tank Capacity Mode is
currently off.
2. Turn the Tank Capacity Mode on by pressing . The display will show ON,
and the Alternate Numeric Display and Percent Indicator will turn on.
3. Press to proceed to the first step of training. 0% will flash in the Alternate
Numeric Display indicating that the weight of an empty container must be
registered.
4. Apply an empty container (or a load representing the weight of an empty
container) on the platform. Wait 5 seconds for the load to stabilize, then press
. 100% will flash in the Alternate Numeric Display indicating that the weight
of a full container must be registered.
5. Apply a full container (or a load representing the weight of a full container) on the
platform. Wait 5 seconds for the load to stabilize, then press . This
completes the training process, and the SET TANK indicator will turn off.
6. From this point forward, the Alternate Numeric Display will show the percent of
material remaining in the container from 0% to 100%.
NOTE: The 100% weight must be larger than the 0% weight by at least 200g. If not,
“Err” will show on the Alternate Numeric Display. To clear the error, retrain as above
using a 100% weight that is at least 200g larger than the 0% weight. During training,
the ZERO key may be used to assist in setting the 0% and 100% values. This will
have no effect on the training, as the Tank Capacity Mode relies on absolute, not
relative, weights.
DRS220 User’s Guide
11
Turning Tank Capacity Mode Off
Perform the following steps to turn the Tank Capacity Mode Off:
1. While holding down, press . The SET TANK indicator will turn on, and
ON will show on the display. This indicates that the Tank Capacity Mode is
currently on.
2. Turn the Tank Capacity Mode off by pressing . The display will show OFF,
and the Alternate Numeric Display will turn off.
3. Press to return to normal operation.
Turning the Tank Capacity Mode On without Re-training
The Tank Capacity Mode can be turned back on without retraining. The DRS220 will
remember the previous 0% and 100% set points until the unit is re-trained as above. To
turn the Tank Capacity Mode on without re-training, perform the following steps:
1. While holding down, press . The SET TANK indicator will turn on, and OFF will
show on the display. This indicates that the Tank Capacity Mode is currently off.
2. Turn the Tank Capacity Mode on by pressing . The display will show ON, and the
Alternate Numeric Display and Percent Indicator will turn on.
3. Press to return to normal operation.
Battery Level Indicator
The battery level indicator shows the relative strength of the batteries. Full power is
indicated by four bars. As the batteries are depleted, the number of bars displayed
decreases, until no bars are left. At this point, it is necessary to replace the batteries (refer
to the Battery Installation section above). If the battery power drops to the point where the
DRS220 can no longer function accurately, the alarm will beep 20 times and the power will
turn off automatically. When the batteries are replaced, and the scale is turned back on, the
DRS220 will resume operation with all previous setting intact.
