Fast EtherHub Installation Manual
9
Setting Up 100BASE-TX Stackable Hubs
1.
Put the 100BASE-TX stackable hub on the flat surface.
? Ensure the power is off before stacking the hub.
2.
Attach the power cord and turn on power to the hub.
3.
Connect one end of the D-Sub (25 pins) stack cable to the OUT
port on the first hub and the other end to the IN port on the next
hub in the stack.
? Do not connect OUT to OUT or IN to IN port on different hubs.
4.
Screw on the D-Sub (25 pins) connectors if necessary.
5.
Repeat steps 2-3 until all hubs are combined together in the stack.
You should have a simple chain starting at the OUT port on the
first hub, and ending at the IN on the last hub. You can stack up
to 4 hubs in this manner. Note that a stack acts as a single repeater
set.
?The hub’s backplane ports allow cascading only up to 4 hubs.
