GRN4-600 Chapter 7: Appendix 41 of 50
Chapter 7: Appendix
7-1 Technical Specifications
*The 600+ Shredder can ingest lumps with diameters up to 15.5" (400mm) and weight of 3 to 5 lbs (1.4 to 2.3 kg).
Standard Shredder Specifications 600+
Hopper Feed Opening (inches / mm) 21.7 x 19.3 (550 x
490)
Usable Area of Cutting Chamber (inches / mm) 22.8 x 22.0 (580 x
560)
Machine Size - W x L x H (inches / mm) 53.1 x 39.2 x 91.7
(1350 x 995 x 2330)
Feed Height (inches / mm) 69.9 (1775)
Rotor Speed (rpm @ 60Hz) 72 rpm
Rotor Diameter (inches / mm) 12 (310)
Rotor Width (inches / mm) 24 (600)
Standard Rotor Type Staggered Cutters
# of D2 Rotor Cutters (34mm x 34mm) 26
# of D2 Bed Knives (4 edge) 1 seat, 2 knives
Base Style Gravity Drop
Standard Motor (hp / kW) 15 (11)
Machine Weight (lbs / kg) 5,513 (2500)
Opening Mechanism Mechanical Jack
