800 Series beside-the-press
Chapter 2: Functional Description
14 of 43
Figure: Safety Switch
Opening the Granulator
The Start/Stop lighted push-button provided on the control panel (see figure below) is
used to operate the granulator. The button must be pressed to stop the granulator and
pulled out to start.
Before performing any maintenance or opening the granulator, follow the procedure
below:
1. Turn off the granulator using the provided push-button.
2. Turn the disconnect switch to OFF and lock out power. (If you cannot lock out
power, then remove the power fuses in the control panel.)
3. Tag the machine as “Out of Service”.
4. Make sure the rotor has come to a complete stop.
Wear protective gloves when exposed to knives!
Figure: Control Panel
Start/Stop Push-
Button
Disconnect
switch
