Sterlco A3 Blender Control and Data Acquisition Software User Manual
Page 27
Page Number 27
The pin outs for the cables are as follows:
PC to 1st BLENDER
PIN9
PIN4
PIN1
PIN5
PIN2
PIN8
PIN3
PIN9
BLENDER to BLENDER
PIN4
PIN4
PIN5
PIN5
PIN8
PIN8
PIN9
PIN9
It is best to ring out every pin on every connector to ensure that it is wired
correctly and that there aren’t any shorts prior to connecting the cables to
each blender. Damage to your blenders can occur if you’ve wired this
incorrectly.
ALL CABLES MUST BE RAN IN CONDUIT
