APW EZFILL HOT FOOD WELLS

Part Numbers Beginning with WHFW

INSTALLATION

1.

Water fill is 3/8 (1.0) tubing connection on left back of left controls.

2.

Overflow drain is 1/2” (1.3) OD tube outlet

3.

Main drain is ¾ female NPT.

1. Follow general installation instructions

on page 3.

2. Make applicable Cut-Out per above table.

Unit is designed for installationin

stainless steel tops. Optional wood

mounting kit available.

3. Apply putty tape to the underside

perimeter of the well rim outer edge.

4. Apply a 1/4" (.6) bead of silicone sealant

adjacent to the putty tape on the well

flange.

5. Drop well into opening from the top a n d

push down until entire parameter of rim

is flush with the counter surface.

6. From below the counter surface insert

an 8" to 10" (20 to 25 cm) flat tip

screwdriver into the locking ring tab slots

and twist in a clockwise motion to lock

well in place.

7. Trim excess putty and sealant from

around well rim.

8. Mount control to front panel using

hardware. Maintain 4" (10.2) clearance

between well and front panel.

9. Check nameplate for proper voltage.

Connect power.

10. Connect overflow tube on hot food well

to suitable tubing to handle 212°F water.

Run to open drain.

Electrically

connect units to comply with local and

NEC codes.

Note:

Note:

A 13.981

(35.51)

3.434

(8.72)

Drain

B

Cut-Out

Front Edge

6.0

(15.2)

3.284

(8.34)

5.74

(14.6)

1 Water

Inlet

19.75

(50.2)

11.74

(29.8)

6.50 (16.5)

11.27

(28.6)

4.13

(10.5)

21.88

(55.6)

8.27

(21.0)

2

3

D

E

Hot Food Well

Cut-Out

6.0 (15.2) Minimum

From Counter Edge

2.0 (5.1) Minimum

From Counter Top

Control Cut-Outs

G

H

F

2 Overflow

C

J

8.65

(22.0)

3 Manifold

MODEL

OUTSIDE DIMENSIONS

CUT-OUT

CONTROL CUT-OUT

SHIP WT.

SHFWEZ-2D WELL 29.42” 23.44” 27.79”

13.87”

28.5”

22.5”

5.0”

16.50”

N/A

48 Lbs

(74.2) (59.5)

(70.6)

(35.2)

(72.4)

(57.2)

(12.7)

(41.9)

(21.8 Kg).

A

B

C

J Overflow

D

E

F

G

H

GENERAL SPECIFICATIONS (APW EZFILL HOT FOOD WELLS)

SHFWEZ-3D WELL 43.46” 23.44” 41.83”

27.92”

42.5”

22.5”

5.0”

33.50”

12.50”

68 Lbs

(110.4) (59.5) (106.2)

(70.9)

(108)

(57.2)

(12.7)

(85.1)

(30.8 Kg)

SHFWEZ-4D WELL 57.50” 23.44” 55.87”

27.92”

56.5”

22.5”

5.0”

16.50”

N/A

98 Lbs

(146.0) (59.5) (141.9)

(70.9)

(143.5) (57.2)

(12.7)

(41.9)

(44.4 Kg)

SHFWEZ-5D WELL 71.54” 23.44” 69.92”

41.96”

70.05”

22.5”

5.0”

33.50”

N/A

118 Lbs

(181.7) (59.5) (177.6)

(106.6)

(179.1) (57.2)

(12.7)

(85.1)

(53.5 Kg)

SHFWEZ-6D WELL 85.59” 23.44” 83.96”

41.96”

84.50”

22.5”

5.0”

33.50”

N/A

260 Lbs

(217.4) (59.5) (213.2)

(106.6)

(214.6) (57.2)

(12.7)

(85.1)

(117.9 Kg)

OPTIONS

Description: Lever Operated Drain Valve

Stock Number: 56360

Drain Manifold: Fabricated to Unit, Required

ELECTRICAL RATINGS

1200 EA. @ 208V / 1600 EA. @ 240V

ELECTRICAL RATINGS

1600 EA. @ 208V

VOLTS

WATTS

AMPS

AMPS

VOLTS

WATTS

AMPS

AMPS

(1 Ph)

(3 Ph)

(1 Ph)

(3 Ph)

SHFWEZ-2D WELL 208/240

2400/3200

12 / 14

10 / 12

208

3200

16

14

MODEL

SHFWEZ-3D WELL 208/240

3600/4800

18 / 20

10 / 12

208

4800

23

14

SHFWEZ-4D WELL 208/240

4800/6400

24 / 27

16 / 18

208

6400

31

21

SHFWEZ-5D WELL 208/240

6000/8000

29 / 34

20 / 24

208

8000

39

27

SHFWEZ-6D WELL 208/240

7200/9600

35 / 40

20 / 24

208

9600

47

27

NOTE: CUT-OUT SIZES ARE DIFFERENT FROM STANDARD APW HOT FOOD WELLS (HFW’S)

OPERATION

CLEANING

1. Follow General Operating Instructions on page 3.

1. Follow General Cleaning Instructions on page 3

ELECTRICAL SPECIFICATIONS
