31

54524

Bracket, Solenoid Valve

32

54508

Brass Fitting 1/8 NPT X ¼ Compression

33

54504

Control Box W/assy 12.50"

54522

Control Box W/assy 16.50”

54529

Control Box W/assy 33.50”

34

54512

Hold Down Strap Use With 54510

35

54510

Liquid Level Control Octal Base

XXXX

Liquid Level Control Open Board

36

88977

6-32 X 1.0 Slotted Pan Head

37

54511

Octal Base Use With 54510

38

54503

Bezel Control 12.50”

54521

Bezel Control 16.50"

54529

Bezel Control 33.50”

39

88889

8 X 1/2 AB SMS, Phl Truss

40

56536

Indicator Light (56530)

41

56505

Knob, Thermostat

42

89054

6-32 KEPS Nut

43

54513

Water Solenoid Valve

44

30201

Terminal Block

45

56540

Thermostat 72" Capillary

46

56527

Thermostat 36" Capillary

47

55099

3/4" Conduit 24" Long

48

55058

90° Conduit Connector

49

88993

10-32 X 3/8 Truss Head Screw

50

55059

Anti-Short Bushing

51

87822

Washer Reducing 1 X 3/4

52

89184

7/8" Hole Bushing

53

57258

2 Well Drain Manifold

57273

3 Well Drain Manifold

57267

4 Well Drain Manifold

57293

5 Well Drain Manifold

57366

6 Well Drain Manifold

88961

10-24 Hex Nut, Green-Ground

54578

Tubing, Copper

56542

Dial Plate

54532

Wire Set Two Well

54533

Wire Set Three Well

54534

Wire Set Four Well

54535

Wire Set Five Well

54536

Wire Set Six Well

1

54575

Well Pan W/Assy (w/CopperTubes)

2

55789

Sealant, Permagum

3

54518

Well Pan W/Assy (w/o Tubes)

4

56655

Drain Strainer

5

88971

Screw 8-32 X 1-1/2 SS

6

54545

O-ring For Screw

7

54543

Probe Holder

8

54544

O-ring For Probe Holder

9

89063

Nut, Hex 8-32

10

54548

Spacer, Probe Holder

11

54546

Washer 1/2-20 SS

12

54549

Nut, Hex 1/2-20

13

57264

Well Brace

14

54577

Adapter, 1/4” Tube To 3/8 Pipe

15

55441

Heating Element 208/240V,

54051

Heating Element 208V/1600W

16

89059

#10 External Lockwasher

17

89120

Jiffy Clip

18

89061

10-24 Hex Nut

19

56039

Capillary Cover For Thermostats

20

56506

Reflector Pan

21

89025

10-24 Speed Nut

22

57252

2 WellTop Plate

57260

3 WellTop Plate

57263

4 WellTop Plate

57290

5 WellTop Plate

57363

6 WellTop Plate

23

89073

#8 X 1/2 Sheet Metal Screw

24

55308

E-Z Lock, 6 Tab

25

56050

End Cover

26

56048

Conduit Brace

27

57254

2 Well Front Or Back Cover

57262

3 Well Front Or Back Cover

57266

4 Well Front Or Back Cover

57292

5 Well Front Or Back Cover

57365

6 Well Front Or Back Cover

28

60150

1" X 7" X 48" Insulation HighTemp

29

56388

Hole Cover

30

54526

2 Well Bottom Cover

54538

3 Well Bottom Cover

54539

4 Well Bottom Cover

54540

5 Well Bottom Cover

54541

6 Well Bottom Cover

1200W/1600W

ITEM

P/N

DESCRIPTION

ITEM

P/N

DESCRIPTION

ITEM

P/N

DESCRIPTION

ITEM

P/N

DESCRIPTION

PARTS LIST

HFWEZ-2, -3, -4, -5, -6 EZ FILL MULTI WELLS

HARDWARE NOT SHOWN

17
