Periodic Maintenance Continued Internal Switches
4
I n s t a l l a t i o n G u i d e l i n e s
11
M a i n t e n a n c e / Te c h n i c a l I n f o r m a t i o n
Technical Information
Process:
When:
Per battery manufactures instructions monitor and maintain
proper levels of distilled water (not tap or bottled water that
contains minerals) in each battery.
Monthly
Visually inspect all wiring for cuts and abrasions. Contact
ProMariner if charger needs to be serviced.
Monthly
Process:
When:
Process:
When:
Check charger for water damage.
Monthly
Advanced Electronic Technology
Elapsed Hours
s
p
m
A
Available amperage for house loads
50
40
30
20
10
0 10:
0
00:
2
00:
4
00:
6
00:
8
00:
01
Average Amperage
ProTech 1230
Elapsed Hours
stl
o
V
Fast Charge
(Step 1)
14.6V
13.3V
1-4 hrs.
Absorption Charge
(Step 2)
Float Mode
(Step 3)
16
15
14
13
12
11 10:
0
00:
2
00:
4
00:
6
00:
8
00:
01
Average Voltage
ProTech 1230
Battery Type (S2)
Standard
Lead Acid
Yellow
GEL
Green
1 2
Shown (above) is the battery type indicator switch. The absorption LED will illuminate
green when set to GEL cell. The absorption LED will show yellow in the Lead Acid
and AGM (Absorbed Glass Mat) setting. Shown in GEL mode.
Shown (above) is a diagram for the switch positioning. Example: all switches in
the up position as shown on the diagram equal 1 hour absorption time.
Actual Switches
Switch Positions (S1)
1 2 3
ON
1 Hour
Absorption
1 2 3
ON
2 Hour
Absorption
1 2 3
ON
3 Hour
Absorption
1 2 3
ON
4 Hour
Absorption
Shown (above) - The charger is set for four hour absorption flooded (Lead Acid)
Fast Charge
(Step 1)
Absorption Charge
(Step 2)
Float Mode
(Step 3)
