ProMariner ProMite User Manual

Page 5

Specifications

ProMite5

12 5 1 6’ 6”x 3.65” x 2.5” 5 lbs 90-135

ProMite5/5

12/24 10 2 6’/6’ 9”x 5.25” x 3.5” 8 lbs 90-135

ProMite5/5/3 12/24/+ENG 13 3 6’/6’/6’ 9”x 5.25” x 3.5” 9 lbs 90-135

model volts amps banks DC cable size size L x W x H est. weight AC in

model

part no. cable size volts banks

Handheld DC System Tester

87710

n/a

Remote Battery Bank Status Monitor

51060

10'

ProMite AC Plug Holder (white)

51200

n/a

ProMite AC Plug Holder (black)

51201

n/a

Universal AC Plug Holder (black)

51202

n/a

Universal AC Plug Holder (white)

51203

n/a

Battery Bank Cable Extender

51070

15'

n/a

Battery Bank Cable Extender

51071

n/a

To Place an Order Please Contact Your Local Dealer or ProMariner at:
Tel: 603-433-4440 / Fax: 603-433-4442 / www.promariner.com

Optional Accessories

S p e c i f i c a t i o n s & A c c e s s o r i e s

P r o M i t e O v e r v i e w

General Overview

The ProMite charger is a fully Automatic/ Electronic On-board Marine Battery
Charger. ProMite is prewired for easy installation and is 100% waterproof for fresh
and salt water applications.

The ProMite incorporates a durable one piece plastic housing. The ProMite offers
fully automatic charging which includes a "Float " maintenance mode that is safe
for long and short term storage. ProMite can be left on indefinitely without harming
or over charging your batteries.

Easy to view LED indicators will provide you with AC Power On and Charging Status.
The LED Indicators can be seen from the front and side of the charger when
installed.

The ProMite is available in 3 models and can be used in 12, 24 and 24 volt with
engine battery (model specific) configurations without rewiring or switching. Just
attach the DC output cable terminals as illustrated in the installation section of this
manual.
