BMF Series Media Filter
Operating & Maintenance Manual
PEP Filters • 322 Rolling Hill Road • Mooresville, NC 28117 • 800-243-4583 • www.pepfilters.com
704-662-3133 (Outside USA) Page 9 of 14 Fax 704-662-3155
rev. 01/02
Table 2 Connection Sizes
System (‘tower”) Water Backwash
Filter Inlet Filter Outlet Waste Outlet
Optional
Pump Inlet
City Water Inlet
(for city water backwash)
Filter Model
Inches / mm Inches / mm Inches / mm Inches / mm Inches / mm
BMF 54 4 / 100 4 / 100 4 / 100 3 / 76 4 / 100
BMF 60 4 / 100 4 / 100 4 / 100 3 / 76 4 / 100
BMF 66 4 / 100 4 / 100 4 / 100 4 / 100 4 / 100
BMF 72 6 / 150 6 / 150 6 / 150 4 / 100 6 / 150
BMF 78 6 / 150 6 / 150 6 / 150 4 / 100 6 / 150
BMF 84 6 / 150 6 / 150 6 / 150 6 / 150 6 / 150
BMF 90 6 / 150 6 / 150 6 / 150 6 / 150 6 / 150
BMF 96 8 / 200 8 / 200 8 / 200 6 / 150 8 / 200
Table 3 BMF Filter Flow Rates
Filter Model
Filtration Flow Rate
gpm / lps
Backwash Flow Rate
(minimum)
gpm / lps
Backwash Flow Rate
(maximum)
gpm / lps
BMF 54 318 / 20.1 254 / 16 318 / 20.1
BMF 60 393 / 24.8 314 / 19.8 393 / 24.8
BMF 66 475 / 30 380 / 24 475 / 30
BMF 72 566 / 35.7 453 / 28.6 566 / 35.7
BMF 78 663 / 41.8 530 / 33.4 663 / 41.8
BMF 84 770 / 48.6 616 / 38.9 770 / 48.6
BMF 90 884 / 55.8 707 / 44.6 884 / 55.8
BMF 96 1005 / 63.4 804 / 50.7 1005 / 63.4
Table 4 Electrical Requirements – Three Phase, 60 Hz
Pump
HP / KW
Voltage (three phase)
60 Hz
Full Load Current
Amps
7.5 / 5.6 208, 230, 460, 575 24.2, 22, 11, 9
10 / 7.5 208, 230, 460, 575 30.8, 28, 14, 11
15 / 11.2 208, 230, 460, 575 46.2, 42, 21, 17
20 / 15 208, 230, 460, 575 59.4, 54, 27, 22
