BMF Series Media Filter
Operating & Maintenance Manual
PEP Filters • 322 Rolling Hill Road • Mooresville, NC 28117 • 800-243-4583 • www.pepfilters.com
704-662-3133 (Outside USA) Page 13 of 14 Fax 704-662-3155
rev. 01/02
Description
Key
Filter Model Item
Part Number
1 BMF 96 Over-drain Schedule 80 PVC O-PVC80-BM-96
Note: Refer to factory shop drawing to confirm over-drain materials of construction
2 All Filter Vessel
3 All Control Panel
4 All DP Switch
Consult factory for part number. Provide filter
serial number with your inquiry.
5 BMF 54 Under-drain Header & Laterals U-PVC80-BM-54
5 BMF 60 Under-drain Header & Laterals U-PVC80-BM-60
5 BMF 66 Under-drain Header & Laterals U-PVC80-BM-66
5 BMF 72 Under-drain Header & Laterals U-PVC80-BM-72
5 BMF 78 Under-drain Header & Laterals U-PVC80-BM-78
5 BMF 84 Under-drain Header & Laterals U-PVC80-BM-84
5 BMF 90 Under-drain Header & Laterals U-PVC80-BM-90
5 BMF 96 Under-drain Header & Laterals U-PVC80-BM-96
6 All Pressure Gauge Consult Factory
7 BMF 54, 60, 66 Butterfly Valve 4” Diameter V-VLV-040-BF-WFR-CIB
7 BMF 72 ~ 90 Butterfly Valve 6” Diameter V-VLV-060-BF-WFR-CIB
7 BMF 96 Butterfly Valve 8” Diameter V-VLV-080-BF-WFR-CIB
8 All Pump (optional)
8 All Pre-strainer (optional)
Consult factory for part number. Provide filter
serial number with your inquiry.
9 Valve Linkage Kits: Select either “C” or “T” for City or Tower water backwash
9 BMF 54 Automatic City or Tower L-LA-BM-054-A- C or T
9 BMF 54 Manual City or Tower L-LA-BM-054-M- C or T
9 BMF 60 Automatic City or Tower L-LA-BM-060-A- C or T
9 BMF 60 Manual City or Tower L-LA-BM-060-M- C or T
9 BMF 72 Automatic City or Tower L-LA-BM-066-A- C or T
9 BMF 72 Manual City or Tower L-LA-BM-066-M- C or T
9 BMF 78 Automatic City or Tower L-LA-BM-072-A- C or T
