Page 2
8077-F
Software is not bundled with this product. Please confirm that the program you select will operate properly according to the communication
protocol and conditions listed below. ID data is stored in ROM and therefore will not be cleared when the unit is turned off.
٨ Do not use excessive force when inserting a wire into the wire insert point. Damage may result to the terminal or product.
Caution
3.How to use (ASCII command requirements)
Communication protocol
@
ޓ? ޓ? ޓ1 ޓ2 ޓ> ޓ!
Header
ID1
ID2
Command
Data1
Data2
End code
Header
㧬㨇40H㨉
End code
!
㨇21H㨉
ID
Command
0
㨇30H㨉̖ActionOFF
1
㨇31H㨉̖ActionON
? [3FH] --- Create or change ID
Data
٨Command to operate 1-8 outputs
٨Command to set ID # when ID is used (optional)
This example operates switches # 6,4,3 and2.
Programming example as above executes the commands set on No.6,4,3 and 2.
Example input
Letter(ASCII code)
Bit data
Action No.
Data1
2
㨇32H㨉
0 0 11 0 0 1 0
8 7 6 5
Data2
>
㨇3EH㨉
0 0 11111 0
4 3 2 1
1 bite
2 bite
1 bite
2 bite
1 bite
The default ID is ?? [3FH 3FH].
In this case, the unit does not use an ID.
Examples
Serial communication specification
Reply code
Header
ID1
ID2
command Data1 Data2 End code
㧬
?
?
1
0
8
㧍
40H
3FH
3FH
31H
30H
38H
21H
ASCII code
HEX code
٨To excute the command of No.4 on
00110000B 00111000B
Header
ID1
ID2
command Data1 Data2 End code
㧬
?
?
0
?
?
㧍
40H
3FH
3FH
30H
3FH
3FH
21H
ASCII code
HEX code
٨To cancel all the commands
00111111B
00111111B
Header
ID1
ID2
command Data1 Data2 End code
㧬
2
3
?
4
6
㧍
40H
32H
33H
3FH
34H
36H
21H
ASCII code
HEX code
٨To change ID of PHC-100A from 23[32H*33H] to 46[34H*36H]
Communication specification
RS-232C compliant
Communication speed
9600bps
Data length
8 bit
Stop bit
1 bit
Parity
Any setting
Any setting
synchronous mode
Flow control
Synchronous mode
Transmission mode
Half-duplex mode
Transmission code
ASCII code
Reply code
ACK
㨇06H㨉
NACK
㨇15H㨉
̪The product does not work if a command is sent before ACK(06H) is replied.
Reply code
E
㨞㨞㨛㨞 contents
When a command, other than 0[30H], 1[31H] or ?[3FH], is set
When data, other than 0[30H] - ?[3FH], is used
Reply interval between data is
more than 5 seconds after receipt of header
Transmission condition
ACK
㨇06H㨉When data transmission is finished
NACK
㨇15H㨉Command error
Data error
Timeout
Connect the (straight) cable DSUB9P (female) connector to the PHC-100A communications port.
Connect the other end of the cable to your PC or DTE device
̪
عPHC-100A
ع㧼㧯
Refer to instructions manual of PC
when connecting this product to
PC with RS-232C straight cable.
AC
adaptor
120V AC
ASCII code
Hex
0
1
2
3
4
0
NUL
DLE
Space
0
@
1
SOH
DC1
!
1
A
2
STX
DC2
"
2
B
3
ETX
DC3
#
3
C
4
EOT
DC4
$
4
D
5
ENQ
NAK
%
5
E
6
ACK
SYN
&
6
F
7
Bell
ETB
'
7
G
8
BS
CAN
(
8
H
9
HT
EM
)
9
I
A
LF
SUB
*
:
J
B
VT
ESC
+
;
K
C
FF
FS
,
<
L
D
CR
GS
-
=
M
E
SO
RS
.
>
N
F
SI
US
/
?
O
Higher code
Lower code
Connection cable
Signal
PHC-100A
Shield
Pin No.
FG
-
TXD
3
RXD
2
RTS
7
CTS
8
SG
5
Signal
㧔PC㧕
Data output
Pin No.
-
1
3
2
2
3
7
4
8
5
5
7
FG
TXD
RXD
RTS
CTS
SG
D-SUB9P D-SUB25P
D-SUB9P
ع
Reset switch
All commands can be reset by pressing a reset switch.
While the reset switch is pressed, this product does not
accept any communication commands, and then, CTS line of
RS-232C will be at low level.
3.Wiring example
The internal contacts are non-voltage contacts (relay contact). They operate products which contact capacity is under AC125V
3A or DC30V3A.
The products having the different voltage can be connected to each contact, since each contact is independent.
̪The example listed above is in the case of the 120V AC product. The direct current product of DC 30V or less also can be connected.
RS-232C Straight cable
Power operating
㧦In the case of products operated by power supply(When the 120V AC product is used)
عWiring example 1
㧨
AC adaptor connection
㧪
٨Block diagram
٨Wiring diagram
ψ120V AC
120V AC
φ
120V AC
㧨PC㧪
RS-232C Straight
cable
< Warning lights etc. >
㧨PHC-100A㧪
AC adaptor
(bundled)
PC
PHC-100A
㧨PC㧪
㧨PHC-100A㧪
RS-232C straight
cable
RS-232C Straight
cable
120V AC
ޓ
φ
㧨AC adaptor connection㧪
Signal light
Audible alarms
etc.
lead wire 1
lead wire 2
lead wire 3
COM wire
ψ 120V AC
1.Wiring to the terminal block
2.Connecting the RS-232C cable (Not supplied with the PHC-100A)
٨Terminal block
٨How to make wiring connection
Ԙ Strip the wire insulation back 9 mm
ԙ Depress the connect-disconnect lever with a slotted screwdriver
Ԛ While holding the lever depressed, insert the wire
ԛ Remove the screwdriver to and check that the wire does not come out easily
Connect-disconnect lever operation
A slotted screwdriver
ޓnominal size 4.5mm50mm
Applecable wire
9mm
A solid wire
ޓǾ0.4㨪Ǿ1.2mm 㧔AWG26㨪18㧕
A twisted wire
ޓ0.3㨪0.75mmޓ㧔AWG22㨪20㧕
̪When using stranded wire, the strand should be more than 0.18 mm diameter.
2
A slotted screwdriver
9mm
Connect-disconnect lever
Wire insert point
120V AC
120V AC
Warning
lights
RELAY
No.8
Lead wire operating : In the case of products operated by lead wire. (When the 120V AC product is used)
عWiring example 2
٨Block diagram
٨Wiring diagram
AC adaptor
(bundled)
PC
PHC-100A
120V AC
Signal
light
RELAY
No.8
RELAY
No.7
RELAY
No.6
ធὐኈ㊂ ޓޓޓޓޓޓޓ߹ߢ
Contact capacity
125V AC,3A
30V DC,3A
8
7
6
5
4
3
2
1
ធὐNo.(Relay contact No.)
㔚✢ⵍⷒ߈㐳ߐ㧦9mm(Strip)
න✢:Ǿ0.4㨪1.2mm(Single wire)
᠐✢:0.3㨪0.75mm 2(Twist wire)
MODEL
PHC-100A
Reset switch
RS-232C
Power
24V DC
↪ น ⢻ 㔚 ✢
A p p l i c a b l e w i r e
Strip length
