Noby-220iiiiR2 Installation Manual Page 2 Software Revision1-0
- - -
Contents Page
Noby-220iiiiR2 Overview 3
Installation and Commissioning 6
Location and mounting the Noby-220iiiiR2 6
Connecting the 230VAC supply 6
First power up 7
Connecting the detectors 7
Connecting the external sounders 7
One-man test 8
Automatic Re-sound Option 8
Input / Output Terminals 9
External Fault Input 9
Fault Output 9
iiii nterlink Data Bus 10
iiii nterlink Programming 10
LED Strobe / Lamp Output 13
Relay Output 13
Engineer Disablement Options 14
Panel Behaviour 15
Audible alarms, faults & warnings 15
Panel Reset 15
LED Lamp and 230VAC Mains Loss 15
Maintenance 15
Troubleshooting 16
Warnings & Cautions 17
Specification 18
User Operation 21
LED Display Indications 22
