www.milestonesys.com Page 14 Default Settings
Default Settings
Default settings can be activated by pressing the “Default settings” button from the Setup Form.
The default setting including:
•
COM Port: “COM1”.
•
Baud: 9600, Parity: Odd, Data bits: 8, Stop Bits: 1, and Handshake: RequestToSend
•
Generic numbers:
o all not assigned
•
PELCO KBD300A spec:
o ACK - Select Generic number.
o Joystick - default joystick move motions such as pan left/right/stop, tile up/down/stop, and zoom
in/out
o NEAR/FAR - Focus up/down/stop
o OPEN/CLOSE – Iris up/down/stop
o HOLD – Playback stop
o FORWARD/REVERSE – Forward playback /Reverse playback
o NEXT/PREV – Next image/Previous image
o MON – Select monitor
o CAM – select camera
o F1 – Show live
o F2 – Show browse
o F3 – Show setup
